Mini 81keys Industrial PC Keyboard with trackball

Mini 81keys Industrial PC Keyboard with trackball

Views:50

Model No.:CG19320

Price Terms: FOB or EXW

Price: US$ 6~19/Piece | Get Latest Price

Payment Terms:L/C,D/A,D/P,T/T,Western Union,Paypal

Delivery Lead Time: Negotiable

Port: Shenzhen or HK,China

Email us

Product Detailed Description

Special Features:


1. IP68 dynamic rated washable 25mm stainless steel optical trackball module with 800 DPI resolutions
2. Function keys F1, F2..F10, F11, F12 are on the top panel for easy operation

3. 3 mouse buttons designed for right & left clicking and scrolling up and down with ball rolling
4. Rear panel mounting solution

5. Ease of customizing with multiple languages, to accommodate foreign or custom variants.

6. PS/2, USB connection plug-and-play with PC via PC existing OS driver

7. Industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm

 for stable and accurate data input

8. CE,RoHS,FCC certified,IP65 test report



Applications:


This Keyboard is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.




Specifications:



MECHANICAL DATA

Key

81 keys, super quality SUS304 brushed stainless steel

Key top style

Non-Protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available

Key Size

10.0mm x 10.0mm for normal keys,
10.0mm x 20.0mm for enter key,
10.0mm x 75.0mm for space bar.

Key travel

0.45mm

Tracker ball

25.1mm (1.0’) diameter,
IP65 static 400DPI mechanical trackball,
IP68 dynamic washable 800DPI optical Trackball

Switch life

more than 5 million of operations

Actuation Force

1.50N+/-0.1N for key 10.0mm x 10.0mm (pressure point),
3.0N+/-0.1N for key 10.0mm x 20.0mm (pressure point)

Front Plate

1.5mm thickness super quality brushed stainless steel

Back Plate

3.0mm thickness brushed & oxidized aluminum

Actuator/keys materials

stainless steel

G.W.

1.30KGs

Dimensions

255.0mm x 105.0mm (top panel) , 275.0mm x 117.80mm (rear panel)
