MULITI-LINE LASER LEVEL
| Model No. | CG18008 |
|---|---|
| Sample Time | 7 days |
| OEM / ODM | Available |
| Port | Shenzhen or HK,China |
| Views | 2218 views |
US$ 5~11 /Piece | Get Latest Price
Product Detailed Description
The multi-line laser level self-levels quickly and includes a rotation base with scale, a pendulum locking system, and a folding leg for setup on site. A 5 mW semiconductor laser diode projects three 635 nm lines and one 650 nm line in laser safety class Class II, with horizontal accuracy of ±1mm/10m and vertical accuracy of ±1mm/10m. The down dot accuracy is ±0.5mm/0.5m and the zenith dot accuracy is ±1mm/3m. The self-leveling range is ±3°, self-leveling time is ≤5 seconds, and the laser line fan angle is ≥120°. The operating range is 15M, powered by 3pcs AA battery with continuous operating time of around 12hours.
- Laser source: 5mw semiconductor laser diode
- Wave length: 3 x 635nm, 1 x 650nm
- Laser safety class: Class II
- Horizontal accuracy: ±1mm/10m
- Vertical accuracy: ±1mm/10m
- Down dot accuracy: ±0.5mm/0.5m
- Zenith dot accuracy: ±1mm/3m
- Self leveling range: ±3°
- Self leveling time: ≤5 seconds
- Laser line fan angle: ≥120°
- Operating range: 15M
- Power: 3pcs AA battery
- Continuous operating time: around 12hours
- Unit dimensions: 160×160mm
- Unit weight: 250g
- Operating temperature: -5°---+45°
- Unit tripod mount: 5/8" x11
- Adjustable range of foot screw: ±8°
- Self-leveling quickly
- Rotation base with scale
- Pendulum locking system
- With the folding leg
