Industrial pc desk top keyboards / numeric keypad with touchpad

Product Detailed Description

IP65 industrial & military keyboard with adjustable industrial backlight and IP65 dynamic sealed & ruggedized tough touchpad (optional scroll function). The keyboard features carbon-on-gold key switch technology with a 1.50mm key stroke for fast and accurate input without noise. Key tops are laser-etched or high quality ink print for easy readability and long life. The device uses PS/2 or USB connection output cables that plug directly into the host computer.

• IP65 dynamic vandal proof industrial & military keyboard with 71 keys
• Adjustable industrial backlight and IP65 dynamic sealed & ruggedized tough touchpad with scroll function (optional)
• Carbon-on-gold key switch technology with 1.50mm key stroke
• High quality durable black titanium electroplated on the top stainless steel plate (optional)
• NVIS-compliant adjustable red backlighting for military, aviation or vehicle applications
• Strong polymer keys ensure resistance to willful destruction, vandal-proof, against corrosion, weather-proof under hostile environments
• Waterproof execution according to degree of protection IP65 from the panel
• Key tops are laser-etched or high quality ink print in legends and characters
• Multiple languages for easy customization
• Operational life of more than 10 million cycles per key
• Resistant to most commonly used cleaning agents
• Integral IP65 dynamic sealed and ruggedized tough touchpad, 38mm trackball optional
• Constructed to survive in exposed, unsupervised, public environments
• Hardened stainless steel front plate and polymer keys ensure resistance to hard use, abuse and vandalism

• MECHANICAL DATA
• Key: 24 keys
• Key top style: Protuberant rectangular keys
• Actuator/keys materials: Polymer
• Top SS plate: 1.5mm stainless steel plate with super quality durable Black Titanium Electroplated (optional)
• Robust polycarbonate frame
• Key Size: 11.4mm x 11.4mm for normal keys, 11.4mm x 24.3mm for enter key
• Key travel: 1.50mm
• Switch life: more than 10 million of operations
• Lettering: laser-etched or high quality ink print
• G.W.: 1.0KGs
• Dimensions: 380.0mm x 108.0mm ( L x W )
• Touchpad cover: Composite
• Lifetime: More than 10 million strokes Mutual Capacitance sensing
• X/Y position sensing resolution: 40 counts/mm
• X/Y position reporting: Relative
• Output: PS2 or USB
• Tracking speed: Maximum 1,016 m/sec
• Power supply voltage: 5 VDC ±0.25V
• Current rating (active mode): 17 mA
