Industrial PC Keyboard with ruggedized touchpad

Industrial PC Keyboard with ruggedized touchpad

Views:1073

Model No.:CG19329

Price Terms: FOB or EXW

Price: US$ 2~18/Piece | Get Latest Price

Payment Terms:L/C,D/A,D/P,T/T,Western Union,Paypal

Delivery Lead Time: Negotiable

Port: Shenzhen or HK,China

Email us

Product Detailed Description

 Quick Details:
1. IP65 dynamic vandal proof stainless steel industrial kiosk keyboard with touchpad
2. IP65 dynamic sealed & ruggedized tough touchpad
3. CE,RoHS,FCC certified,IP65 test report.
Descriptions:
1. 67 keys compact format IP65 dynamic vandal proof stainless steel industrial keyboard
2. IP65 dynamic sealed & ruggedized tough touchpad with scroll function (optional) for fast and accurate cursor position
3. 3.industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile
feeling for stable and accurate data input
4. Rear panel mounting solution.
Special Features:
1. Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design,
functionality, longevity and high protection level.
2. Stainless steel fascia and key-tops guard willful destruction, vandal-proof, against corrosion, weather-proof especially
under extreme climatic conditions, water proof/dirt proof, operation under hostile environments.
3. Waterproof execution according to IP65 protection from top panel, rear aluminium plate with mounting holes easily &
tightly mounting to enclosure or panel.
4. An excellent tactile feel with short stroke switches and allow users to achieve stable and accurate data input, with firm
tactile perception for comfortable operation
5. Internet friendly key layout, key-tops are laser-etched in legends and characters for easy readability, long life to prevent
lettering rub-off.
6. Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key
covers.
7. Ease of customizing with multiple languages, to accommodate foreign or custom variants.
8. Complete electronic modules including controller in close consultation with our customers are available.
9. PS/2, USB connection plug-and-play with PC via PC existing OS driver, no needing of install separate driver.
Applications:
This Keyboard is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.
Specifications:

MECHANICAL DATA

Key

69 keys, super quality brushed stainless steel

Key top style

Non-Protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available

Key Size

10.0mm x 10.0mm for normal keys
10.0mm x 20.0mm for enter key,
10.0mm x 75.0mm for space bar.

Key travel

0.45mm

Switch life

more than5 million of operations

Actuation Force

1.50N+/-0.1N for key 10.0mm x 10.0mm (pressure point),
3.0N+/-0.1N for key 10.0mm x 20.0mm (pressure point)

Front Plate

1.5mm thickness super quality brushed stainless steel

Back Plate

3.0mm thickness brushed & oxidized aluminium

G.W.
