P65 dynamic industrial pc keyboard with integrated touchpad

Product Detailed Description

Quick Details:
1. Durable and anti-microbial keyboard surface 2.IP65 dynamic scratch proof industrial membrane keyboard with integrated function keys and touchpad
3. Clean key for easy cleaning via lock/disable the entire keyboard without needing to take the keyboard from PC
Descriptions:
1. Ruggedized and backed with 3.0mm alumium plate with sand blasting & oxygenation treatment 2. 88 keys IP65 dynamic rated compact format industrial membrane keyboard with integrated function keys on the upper line
3. IP65 dynamic sealed and ruggedized tough touchpad for fast and accurate cursor position
4. 2.0mm thickness industrial metal dome PCB with gold-on-gold metal dome key switch technology with short stroke 0.45mm with extremely tactile feeling for reliable data input
5. With Clean key for easy cleaning via lock/disable the entire keyboard without needing to take the keyboard from PC
6. Surface mounted extremely flush with anti-microbial, durable and scratch-proof polyester withstand to most chemicals and liquids under the harshest environments
7. Panel mounted solution.
Special Features:
1. Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionality
2. The foil-covered aluminum front plate is mounted flush for easy cleaning.
3. The keyboard lacks the crevices found between the keys of a regular keyboard, which is protected against dust, dirt,grease and corrosive liquids to NEMA 4X, which means it can withstand directed hose water, disinfectants, environmental contaminants and heavy industrial use.
4. PS/2, USB connection cables that plug directly into computer like keyboard operations.
5. Ease of customizing with multiple languages, to accommodate foreign or custom variants.
6. This stylish, rugged medical keyboard is ideal for any application requiring a rugged enclosure and low profile.
7. Clean key -Prevents data from being sent while the keyboard is wiped down, allowing user to clean at any interval with minimal downtime
Applications:
This keyboard is ideal for use in environments ranging from manufacturing to material handling to medical settings.
Its numeric pad allows for easy data entry.
A: MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;
B: MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc
C: INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing environments, warehouses etc
D: OTHER INDUSTRIES
Specifications:

MECHANICAL DATA

Key

88

Key switch Technology

metal dome PCB with gold-on-gold metal dome key switch technology with short stroke keys

• Actuation Force:
• 1.0N for key 13.0mm x 13.0mm (press point)
• Key travel
• 0.45mm
• Key switch Lifetime
• 3 mil. operations
• Protection Level
• IP65, NEMA 4x
• Mounting Type
• Front panel mounting
• Operating Temperature
• -20 °C to +50 °C
• Colors
• 4 (Blue, White, Grey, Black)

G.W.

1.50KGs

• Key Dimensions
• (print area)

13.0mm x 13.0mm

Dimensions

304.40mm x 195.8mm (top panel)
